LaserHyde Thermal Adhesive Film

premium quality & superior products

LaserHyde Thermal Adhesive Film Pre-Cut

Laserhyde Thermal Adhesive Film Pre-Cut – Low Temp 12″x20″

(0 customer reviews)
LASERHYDE IS THE #1 ADHESIVE FOR HAT PATCHES!

…

Our professional grade industrial strength Laserhyde thermal adhesive heat press pre-cut film, features amazing water resistance, with awesome low heat application temperatures that help reduce scorching risk on your custom fabric and hat projects. Our adhesive is easy to manully and laser cut, and is laser safe with an OEKO-TEX Standard 100 certification, which makes using laserhyde adhesive the perfect choice for hat patches, embroidery patches, washable apparel, hard surface products and so much more.

Price

Price range: $38.75 through $260.00

Choose A Quantity

Earn up to 520 Esentl Points.

- +
Facebook Youtube Instagram

LaserHyde Thermal Adhesive Film Pre-Cut – Low Temp 12″x20″

Laserhyde thermal adhesive film pre-cut, is our leading industrial strength thermoplastic poly adhesive for leather, leatherette hat patches, leatherette panels, velcro fabric mesh, PVC, embroidery, acrylic panels, fabrics, and more, is one of the industry leading film adhesives which feature amazing water resistance, up to 130F. Our Laserhyde™ Adhesive also features superior excellant low application temps, especially when using a Hotronix IQ 360 Hat Heat Press ( as low as 225° F upper platen heat and 270°F lower platen heat). Feel confident and assured that Laserhyde™ thick adhesive heat press film will get the job done, and provide a super strong durable bond with all of your applicable projects.

Laserhyde Adhesive Features
  • Actual true dimensions ( 12 in x 19.75 in )
  • Competitively priced as low as 2.6 cents per square inch ( but a thicker film with better features when compared to other top adhesive competitors)
  • Thermoplastic 2 sided hot melt film heat press adhesive
  • Our adhesive and paper backing offers smooth clean laser cutting
  • Thermal heat activated heat press adhesive sheet
  • 6 mil thickness
  • Water resistant up to 55°C (130°F)
  • Low temperature adhesive film for leather and hat patches (See instructions on page below)
  • Excellent adhesion to most soft and hard textile products
  • Dry Clean friendly
  • Dry to touch application (non tack formula)
  • Cold peel the film after 1st application, or leave the film on for easy clean laser cutting.
  • Laserhyde™ Adhesive is OEKO-TEX Standard 100 Certified
  • Laser-Safe product
Laserhyde Product Applications
  • Leather patch adhesive
  • Leatherette engravable sheet panels
  • Apparel projects
  • Leatherette patches
  • Fabric materials
  • Cosplay projects
  • Wood/Veneer panels
  • Acrylic Sheet panels
  • Acrylic patches
  • Embroidery patches
  • Hat patch adhesive
  • Velcro Hook and Loop Fabric panels (not the smooth backed versions)
  • And more

DONT FORGET TO CHECK OUT OUR LASERHYDE™ LEATHERETTE  ENGRAVABLE SHEETS

IMPORTANT POLICY INFO:

Shipping Policy

Refund & Return Policy

Weight N/A
Dimensions N/A
Sheet Amount

5 Sheets, 10 Sheets, 20 Sheets, 40 Sheets

Reviews

There are no reviews yet

Only logged in customers who have purchased this product may leave a review.

Q & A

Ask a question
There are no questions yet

heat application instructions

Upper platen heat 230F

Lower platen heat 275F

“Make sure your heating element doesn’t have any  heating inaccuracies.”

All heat presses may vary so dial in your settings beforehand for best results.

Pre press your hat for 7 seconds to eliminate any moisture and to loosen up the material, Make sure to mold the hat shape to the platen, you should have no bubbles between the hat and platen it should feel flat to the platen surface.

Peel the paper backing off patch and place the patch on the hat. Some patches may or may not come with a paper backing. The lower heat and pre press should help this patch stay in place slightly. Hold the patch down for 10-15 seconds to melt adhesive a bit, then, Press patch for 35-40 seconds using the Esentl Hat Mat silicone pad which is highly recommended, so that you don’t scorch your hats. Always preheat  your silicone pad first for best results, and through the process, keep it warm.

All patches and finished products are hand wash recommended, but when using LaserHyde water resistant adhesive you can wash or dry clean this product up to 55C (130F)

You can use a light spraying of LA Awesome cleaner to clean any residue on your leatherette patches

  • 6 mil or 0.15mm

For all other hat presses here are some jumping off point setting you can use. As always practice on your machine to dial in your settings as they will vary from machine to machine

Time:
50-60 seconds w/ pad
Temperature:
340-350F
Pressure:
Medium
Cover Pad:
Esentl Hat mat Silicone Pad

Instructions:
Pre-heat your lower platen for 50-60 seconds. Add your hat and pre-heat for 20 seconds (using your silicone pad, prevents scorching and or burn marks). Make sure to mold the hat shape to the platen, you should have no gaps between the hat and the platen, it should be flat to the platen surface. Add patch and Cover with The Hat Mat Silicone flex pad and press.

Application to leather/leatherette Sheet

Heat Press Time

12 seconds dwell time, with a silicone baking cover sheet

clamshell Heat Press Temps

Temperature 230F

Final Press Application (patches etc.)

Heat Press Time

25 seconds without a Silicone rubber mat and 40 Seconds using our hat mat silicone rubber mat.

360 IQ Hat Press Temps

Upper Platen 230F / Lower Platen 275F

Pressure

Medium 5 without a mat, and a 6 using a Silicone rubber mat.

Hat Protection

Recommended - The Hat Mat Silicone Mat
FOAM PADS NOT RECOMMENDED

stop scorching your hats!!

Silicone Hat Protection Kit - The Hat Mat
CLICK TO ORDER the hat mat!

important tips

  • Always use a silicone pad for best results. we do not recommend any foam pads, as the pressure is not as good using those. for post ( preheat ) press use only a silicone pad as well (recommended), use our see our silicone hat mat for best results
  • Always Check your patches before hat placement.
  • Always check your upper heat press platen with a laser temperature gun to ensure accurate temps, before applying GripTec adhesive to your leatherette sheets
  • Store your patches or leatherette sheets in a cool dry place.
  • Lint roll your hats prior to patch placement.
  • keep your adhesive backing free of dust, use a water based wipe to clean any dust off
  • All our tests are done using a Stahls Hotronix 360 IQ Hat press, your settings may vary for any other style leatherette and adhesive or hat press. For Patches upper and lower heat is recommended, which is why we use the 360 IQ.
  • Always order a few extra sheets of leatherette, to dial in your laser engraving and cut settings
